NF FRA5087 - Fig. 2-1 Size and Dimensions of FRA5087 Rack Mount

To Next Page

To Previous Page

2.2 Mounting and installation

FRA5087

2-5

mm-rack

inch-rack

Rack

mounting

plane

Rack

mounting

plane

When replacing printer

roll paper

When replacing printer

roll paper

Caution

A minimum clearance of 151 mm above the main unit is required for paper replacement.

Ensure this allowance when installing.

Caution

Do not just use the rack-mounting flanges when housing in the rack. Provide a shelf or

L fittings to hold the main unit on the rack.

Fig. 2-1 Size and dimensions of FRA5087 rack mount
