3.5 Examples of basic operations
FRA5087
3.5 Examples of basic operations
3.5.1 Menu operation
Much of the FRA5087 setting is in reference to menu operations shown on the LCD screen. The
figure indicates the screen without menus as it appears immediately after startup.
OSC: 100.0000000kHz 1.00 Vpeak DC 0.00 V INTEG: 1cycle HMNC: 1
SWP: 100steps/sweep CPRSN:OFF SLSWP:OFF ANAL:CH1/CH2 EQL:OFF
SWEEP STOP
1
2
3
4
5
6
Measuring
conditions
Screen tag
select
Status
Fig. 3-5 Screen directly after start
Measuring conditions
The present main settings (measuring conditions) of the FRA5087 are shown. The
abbreviations are defined as follows.
・OSC : Oscillator conditions are indicated. In sequence from the left are frequency,
waveform, AC voltage and DC bias. When output is, AC voltage and DC bias are
indicated as 0 V.
・INTEG : Number of integrations and integration time
・HMNC : Order of harmonics to be analyzed
・SWP : Sweep resolution
・CPRSN : Compression on/off
・SLSWP : Slow speed high density sweep on/off
・ANAL : Analysis mode
・EQL : Equalizing on/off
