9.10 Peripheral input/output functions

FRA5087

9-13

9.10 Peripheral input/output functions

●GPIB

Interface feature SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT0, C0

●USB

Standard USB1.1(Low Speed, Full Speed)

Connector Rear panel, USB-B connector

Device class TMC

●Thermal printer

A hardcopy of the LCD screen displaying the measurement data can be outputted from the

built-in thermal printer

Paper width 112 mm

Suitable paper TP-451C (Seiko Instruments Inc.)

●DC power output

Power output used for our signal injector probe 5055 (sold separately)

Connector Rear panel, AUX connector

Output voltage Approximately 24 V

Output current Maximum 100 mA
