FRA5087
Preface
Thank you for purchasing “FRA5087 Frequency Response Analyzer”.
Please read, first of all, “Safety Instructions: To safely use the frequency response
analyzer” on the next page, so that you can use the instrument in the correct and safe
manner.
●Notes on marks, symbols and terminology used in this Manual
The marks shown below are used in this Manual to indicate Warning and Caution instructions.
Please carefully follow the instructions that are indicated by these marks, so that users or operators
are safe in using the instrument and that the instrument will not be damaged during operation.
Instructions are given to avoid such potential hazardous situations that
instrument operators would be involved in a risk of facing death and/or
personal injury due to an electric shock or other reasons.
Instructions are given to avoid possible instrument damages due to incorrect
use/operation of the instrument.
●This Instruction Manual comprises the following Chapters.
Please read the Manual from the very beginning, i.e., from Chapter 1, if you use this type of
instrument for the first time. Meanwhile, please advised that the instructions for the GPIB and
USB interface are included in a separate manual.
1. Introduction
This Chapter involves such information as overview, features, applications, functions
and operational principles of the instrument.
2. Preparations before using the instrument
Information is given in this Chapter on what should be done by users and other people
concerned before you use the instrument. The information includes installation of the
instrument.
3. Panels; indications and operations
Descriptions are provided in this Chapter on displays and basic operations of the
instrument as well as on keys, indications and other parts located on panels.
Please also read this Chapter while you operate the instrument.
4. Examples of applications
Wider ranges of operational procedures are described in this Chapter for some
applications.
5. Impedance display function (option)
Operation of the impedance display function is described.
6. Files
Descriptions are given for file formats.
7. Trouble-shooting
Error messages and their implications are described.
8. Maintenance
Procedures of performance testing of the instrument are described. Information on
storage, re-packaging and transportation is also provided.
9. Specifications
Instrument specifications are provided in regard to functions and performance.
