1.3 List of functions
FRA5087
1-4
1.3 List of functions
The following shows a list of important functions of the instrument. Thereunder, the function tree
of instrument functions is illustrated.
Functions
general descriptions
Oscillator subsystem OSC
Setting parameters of built-in oscillator such as
frequency and amplitude
Analyzer subsystem input
Input
Setting analyzer input parameters such as excessive
level detection threshold
Measurement control Measure
Setting sweeping parameters, number of integration
times, etc.
Graphic display control
Graph
Setting graphic display format, etc.
Calculation Calc
Calculation of measurement data
Memory Memory
Storing measurement data into internal memory, etc.
Output control Output
Functions related to GPIB and printed output
Disk Disk
Functions related to USB flash drive
Calibration Calib.
Automatic calibration capabilities
Automatic sequencing Autoseq
Automatic process execution in sequence
Others Others
Setting time, etc.
Oscillator subsystem
OSC
Output on AC/DC ON
AC/DC OFFOutput off
On/off mode
Frequency
Amplitude
DC bias
Stop mode
Waveform
AC OFF
QUICK/SLOW
ZERO
HOLD
PHASE START/STOP phase
Sinusoidal waveform
Rectangular waveform
Triangular waveform
Analyzer subsystem input
Input
Excessive
level detection
CH1 detection level
Input channel
weighting
Actions buzzer
CH2 detection level
buzzer
stopping sweep
oscillator output off
CH1 coefficient
CH2 coefficient
Phase invert
