4.19 Condition display
FRA5087
4.19 Condition display
Press the CONDITION VIEW key to display, in the right-hand half window of the screen, the
measurement condition of the graph currently displayed on the LCD screen. At every time you
press the key, the condition display is repeated on and off, alternatively. Note that measurement
conditions displayed as described here are collateral to individual set of data (i. e., they are a part
of individual .DAT files).
Note that the measurement condition displayed when you press the
CONDITION VIEW key is the condition under which the currently displayed
data have been measured, but not the current FRA5087 condition which has
been set for measurement.
4.20 Other functions
Use the menu [Others] to set the built-in clock, etc.
[TITLE SET] : To give/set a title to the displayed data. The title given/set will be
displayed at the top portion of the graph on the LCD screen and stored
with the data.
[BUZZER] : Set this “ON” to activate the sound of buzzer at every time a message is
displayed. Use the menu [Input] to set the buzzer (ON/OFF) to notify the
overload status of the input level. Note that you cannot set the buzzer off
which buzzes at every key action.
[DATE SET] : To set the year, month and date.
[TIME SET] : To set the hour and minute.
[INITIALIZE] : To initialize all parameters/conditions to be set.
[SYSTEM] : The FRA5087 software version and options can be checked.
