5.4 Operation method
FRA5087
5-8
5.4.2 Graph units setting
The impedance display option adds units setting to the menu [DISPLAY MODE] [FORMAT]
[DISPLAY MODE].
The display units setting is selected for gain and impedance.
The graph display units are determined by [UNITS] and [ANALYSIS MODE] setting. Display
units are indicated in Table 5-3.
Impedance display is fixed at voltage for CH1 input and current for CH2 input.
Table 5-3 Display units
ANALYSIS
GAIN
IMPEDANCE
CH1
GAIN[Vrms]
GAIN[dBV]*1
GAIN[Vrms]
GAIN[dBV]*1
CH2
GAIN[Vrms]
GAIN[dBV]*1
GAIN[Arms]
GAIN[dBA]*2
CH1/CH2
GAIN[E+00]
GAIN[dB]
IMPD[]
IMPD[dB]*3
CH2/CH1
GAIN[E+00]
GAIN[dB]
ADMT[S]
ADMT[dBS]*4
Notes
1. 1 Vrms = 0 dBV
2. 1 Arms = 0 dBA
3. 1  = 0 dB
4. 1 S = 0 dBS
