6.3 File format
FRA5087
6-8
Table 6-4 b) Measurement condition file format - Condition data
Offset
Type
Descriptions (content)
40(0x28)
long
Direction of valid line marker 0:horizontal direction movement,
1:vertical direction movement
44(0x2c)
long
Delta marker ON/OFF 0:normal marker, 1:delta marker
48(0x30)
long
OSC ON/OFF mode 0: QUICK, 1: SLOW
52(0x34)
long
“REPEAT” lamp 0:off, 1:on
56(0x38)
long
(not yet used)
60(0x3c)
long
Buzzer buzzing at excessive input level (over) 0:OFF, 1:ON
64(0x40)
long
Measurement termination at excessive input level (over)
0:OFF, 1:ON
68(0x44)
long
Oscillator output turned off at excessive input level (over)
0:OFF, 1:ON
72(0x48)
long
Manual sweep 0:OFF, 1:ON
76(0x4c)
long
Equalizing function 0:OFF, 1:ON
80(0x50)
long
Automatic integration function 0:OFF, 1:ON
84(0x54)
long
Amplitude compression function 0:OFF, 1:ON
88(0x58)
long
High-density slow sweep 0:OFF, 1:ON
92(0x5c)
long
Auto-scale 0:OFF, 1:ON
96(0x60)
long
Grid display 0:OFF, 1:ON
100(0x64)
long
Marker display 0:OFF, 1:ON
104(0x68)
long
(not yet used)
108(0x6c)
long
(not yet used)
112(0x70)
long
(not yet used)
116(0x74)
long
(not yet used)
120(0x78)
long
(not yet used)
124(0x7c)
long
(not yet used)
128(0x80)
long
(not yet used)
132(0x84)
long
(not yet used)
136(0x88)
long
Buzzer buzzing 0:OFF, 1:ON
140(0x8c)
long
Open calibration function 0: off, 1: on (standard version is
always off
144(0x90)
long
Short calibration function 0: off, 1: on (standard version is
always off
148(0x94)
long
Phase invert 0:off, 1: on
152(0x98)
short
Oscillator (OSC) output wave form 0:sinusoidal waveform,
1:rectangular waveform, 2:triangular waveform
154(0x9a)
short
(not yet used)
156(0x9c)
short
Sweep resolution (Log steps/decade)
158(0x9e)
short
Sweep resolution (Log steps/decade)
160(0xa0)
short
Sweep resolution (Lin steps/sweep)
162(0xa2)
short
Integration period (cycle)
164(0xa4)
short
Delay period (cycle)
