6.3 File format
FRA5087
6-9
Table 6-4 b) Measurement condition file format - Condition data (continued)
166(0xa6)
short
Order of harmonics analysis 1 - 10
168(0xa8)
short
Automatic integration mode 0:SHORT, 1:LONG
170(0xaa)
short
Coherence mode 0:CH1&CH2, 1:CH1, 2:CH2
172(0xac)
short
Maximum integration period for automatic integration
174(0xae)
short
Reference channel for amplitude compression 1:CH1, 2:CH2
176(0xb0)
short
Permissible error for amplitude compression 0 - 100(%)
178(0xb2)
short
Maximum number of trials of amplitude compression
1 - 9,999 (times)
180(0xb4)
short
Compensation factor for amplitude compression 0 - 100(%)
182(0xb6)
short
High-density slow sweep mode 0:MANUAL, 1:AUTO
184(0xb8)
short
Reference channel for high-density slow sweep operation
1:CH1, 2:CH2
186(0xba)
short
Graph style 0:SINGLE, 1:SPLIT
188(0xbc)
short
(not yet used)
190(0xbe)
short
Analysis mode 0:CH1/CH2, 1:CH2/CH1, 2:CH1, 3:CH2
192(0xc0)
short
(not yet used)
194(0xc2)
short
Selection number of mass data
196(0xc4)
short
Selection data for permanent data
198(0xc6)
short
Deletion number of mass data
200(0xc8)
short
Deletion number of permanent data
202(0xca)
short
(not yet used)
204(0xcc)
short
(not yet used)
206(0xce)
short
(not yet used)
208(0xd0)
short
GPIB address 0 - 30
210(0xd2)
short
GPIB delimiter 0:CR/LF^EOI, 1:CR^EOI
212(0xd4)
short
Mass memory number to be saved in USB flash drive
214(0xd6)
short
Permanent memory number to be saved in USB flash drive
216(0xd8)
short
Clock (year) 1970 - 2069
218(0xda)
short
Clock (month) 1 - 12
220(0xdc)
short
Clock (day) 1 - 31
222(0xde)
short
Clock (hour) 0 - 23
224(0xe0)
short
Clock (minute) 0 - 59
226(0xe2)
short
Phase display range 0:180 deg, 1:0 - 360 deg, 2:-360 - 0 deg
228(0xe4)
short
Type of sweep resolution
0:Log steps/sweep, 1:Log steps/decade,
2:Lin steps/sweep, 3:Lin Hz
230(0xe6)
short
Type of specifying number of integrations 0:period, 1:time
232(0xe8)
short
Type of specifying delay time 0:period, 1:time
234(0xea)
short
Type of automatic integration limit value 0:period, 1:time
