6.3 File format
FRA5087
6-10
Table 6-4 b) Measurement condition file format - Condition data (continued)
236(0xec)
short
Type of VARIATION of high-density slow sweep operation
0:dBR, 1:R, 2:, 3:a, 4:b
238(0xee)
short
Measurement mode 0:CH1, CH2, 1:CH1,OSC, 2:OSC,CH2
240(0xf0)
short
Oscillator (OSC) START/STOP phase 0 - 359(deg)
242(0xf2)
short
Type of marker 0:data marker 1:line marker
244(0xf4)
short
(not yet used)
246(0xf6)
short
Oscillator (OSC) STOP mode 0:ZERO, 1:HOLD, 2:PHASE
248(0xf8)
short
Grid type 1:solid line 1:broken line
250(0xfa)
short
Grid mode 0:F, 1:FR, 2:F, 3:FR
252(0xfc)
short
Type of DATA1 for the rules of arithmetic
0:DATA TAG, 1:CONSTANT, 2:IMAGINARY
254(0xfe)
short
DATA1 tag set value for the rules of arithmetic 0 - 6
256(0x100)
short
Mode of the rules of arithmetic operation 0: +, 1: , 2:, 3:
258(0x102)
short
Type of DATA2 for the rules of arithmetic
0:DATA TAG, 1:CONSTANT, 2:IMAGINARY
260(0x104)
short
DATA2 tag set value for the rules of arithmetic 0 - 6
262(0x106)
short
ANSWER tag set value for the rules of arithmetic 0 - 6
264(0x108)
short
DATA TAG set value for differentiation and integration 0 - 6
266(0x10a)
short
Mode of differentiation and integration 0:j, 1:(j)
2
, 2:1/j,
3:(1/j)
2
268(0x10c)
short
ANSWER TAG set value for differentiation and integration 0 - 6
270(0x10e)
short
DATA TAG set value for open- and closed-loop conversion 0 - 6
272(0x110)
short
Type of Tm for open- and closed-loop conversion 0:DATA TAG,
1:CONSTANT
274(0x112)
short
Tm data tag set value for open- and closed-loop conversion 0 - 6
276(0x114)
short
Conversion mode of open- and closed-loop conversion
0:To/(1+To  Tm), 1:Tc/(1Tc  Tm)
278(0x116)
short
ANSWER TAG set value for open- and closed-loop conversion
0 - 6
280(0x118)
short
(not yet used)
282(0x11a)
short
Auto-sequence mode
0:NON-ACTIVE, 1:RUN MODE, 2:WRITE MODE
284(0x11c)
short
Graph display mode X axis
0:logF, 1:F, 2:, 3:A
286(0x11e)
short
Graph display mode Y1 axis
0:dBR, 1:logR, 2:R, 3:, 4:logA, 5:log(-A), 6:A, 7:B, 8:-B
288(0x120)
short
Graph display mode Y2 axis
0: , 1:logB, 2:log(-B), 3:B, 4:OFF
290(0x122)
short
Display units
0: Gain, 1: Impedance (standard version is always gain)
292(0x124)
short
(not yet used)
294(0x126)
short
Bitmap file name number
296(0x128)
short
GPIB/USB 0: GPIB, 1: USB
298(0x12a)
short
(not yet used)
