NF FRA5087 - Page 145

6.3 File format
FRA5087
6-11
Table 6-4 b) Measurement condition file format - Condition data (continued)
300(0x12c)
long[2]
(not yet used)
308(0x134)
double
Oscillator (OSC) frequency (Hz)
316(0x13c)
double
Oscillator (OSC) amplitude set value (Vpeak)
324(0x144)
double
Current oscillator (OSC) amplitude value (Vpeak)
332(0x14c)
double
Oscillator (OSC) DC bias set value (V)
340(0x154)
double
Current oscillator (OSC) bias value (V)
348(0x15c)
double
CH1 excessive (over) level detection level (Vrms)
356(0x164)
double
CH2 excessive (over) level detection level (Vrms)
364(0x16c)
double
CH1 WEIGHTING FACTOR 0.0 - 1.0E+06
372(0x174)
double
CH2 WEIGHTING FACTOR 0.0 - 1.0E+06
380(0x17c)
double
Maximum sweep frequency 0.1E3 – 10E+6
388(0x184)
double
Minimum sweep frequency 0.1E3 – 10E+6
396(0x18c)
double
Sweep resolution (Hz)
404(0x194)
double
Integration time (sec)
412(0x19c)
double
Delay time (sec)
420(0x1a4)
double
Maximum integration time for automatic integration (sec)
428(0x1ac)
double
Reference level for amplitude compression (Vrms)
436(0x1b4)
double
Output limiting value for amplitude compression (Vpeak)
444(0x1bc)
double
VARIATION of (dBR) in high-density slow sweep operation (dB)
452(0x1c4)
double
VARIATION of (R) in high-density slow sweep operation (Vrms)
460(0x1cc)
double
VARIATION of () in high-density slow sweep operation (deg)
468(0x1d4)
double
VARIATION of (a) in high-density slow sweep operation (Vrms)
476(0x1dc)
double
VARIATION of (b) in high-density slow sweep operation (Vrms)
484(0x1e4)
double
Display scale initial value : maximum frequency MAX(Hz)
492(0x1ec)
double
Display scale initial value : minimum frequency MIN(Hz)
500(0x1f4)
double
Display scale initial value : dBR MAX(dB)
508(0x1fc)
double
Display scale initial value : dBR MIN(dB)
516(0x204)
double
Display scale initial value : R MAX(Vrms)
524(0x20c)
double
Display scale initial value : R MIN(Vrms)
532(0x214)
double
Display scale initial value :  MAX(deg)
540(0x21c)
double
Display scale initial value :  MIN(deg)
548(0x224)
double
Display scale initial value : a MAX(Vrms)
556(0x22c)
double
Display scale initial value : a MIN(Vrms)
564(0x234)
double
Display scale initial value : b MAX(Vrms)
572(0x23c)
double
Display scale initial value : b MIN(Vrms)
580(0x244)
double
DATA1 constant value in real number for the four rules of
arithmetic operation
588(0x24c)
double
DATA1 constant value in imaginary number for the four rules of
arithmetic operation
