5.4 Operation method
FRA5087
5-6
Table 5-1 (continued)
Units setting
Analyze mode
setting
Axis setting
Axis contents
Scale
Units
IMPEDANCE
CH1
dBR
Amplitude
Linear
dBV
logR
Amplitude
Log
Vrms
R
Amplitude
Linear
Vrms
logA
Amplitude real
Log
Vrms
log(-A)
- amplitude real
Log
Vrms
A
Amplitude real
Linear
Vrms
logB
- amplitude imaginary
Log
Vrms
log(-B)
- amplitude imaginary
Log
Vrms
B
Amplitude imaginary
Linear
Vrms
-B
- amplitude imaginary
Linear
Vrms
CH2
dBR
Amplitude
Linear
dBA
logR
Amplitude
Log
Arms
R
Amplitude
Linear
Arms
logA
Amplitude real
Log
Arms
log(-A)
- amplitude real
Log
Arms
A
Amplitude real
Linear
Arms
logB
- amplitude imaginary
Log
Arms
log(-B)
- amplitude imaginary
Log
Arms
B
Amplitude imaginary
Linear
Arms
-B
- amplitude imaginary
Linear
Arms
GAIN
CH1/CH2,
CH2/CH1
dBR
Gain
Linear
dB
logR
Gain
Log
None
R
Gain
Linear
None
logA
Gain real
Log
None
log(-A)
- gain real
Log
None
A
Gain real
Linear
None
logB
- gain imaginary
Log
None
log(-B)
- gain imaginary
Log
None
B
Gain imaginary
Linear
None
-B
- gain imaginary
Linear
None
CH1,CH2
dBR
Amplitude
Linear
dBV
logR
Amplitude
Log
Vrms
R
Amplitude
Linear
Vrms
logA
Amplitude real
Log
Vrms
log(-A)
- amplitude real
Log
Vrms
A
Amplitude real
Linear
Vrms
logB
Amplitude imaginary
Log
Vrms
log(-B)
- amplitude imaginary
Log
Vrms
B
Amplitude imaginary
Linear
Vrms
-B
- amplitude imaginary
Linear
Vrms
