9.12 Miscellaneous specifications

FRA5087

9-16

●Insulation resistance No less than 20 MΩ (at DC 500 V, between power inputs altogether

and the enclosure)

●Withstand voltage AC 1500 V (between power inputs altogether and the enclosure)

●External dimensions 434 (W) x 177 (H) x 453 (D) mm (without protrusions)

●Weight Approximately 12 kg (weight of the main unit excluding other

matters such as accessories and options)

●Safety EN 61010-1:2010

EN 61010-2-030:2010

●EMC EN 61326:2013 (Group 1, Class A)

EN 61000-3-2:2006+A1:2009+A2:2009

EN 61000-3-3:2013
