5-16 WF1946B
5.4 External Input
 External add (EXT-ADD) (
SYSTEM
: EXT-ADD)
Operation is described for adding an external signal to the 1946B output. The external signal is
connected to the rear panel EXT ADD IN connector.
For details on connectors, “3.2 Input and output connectors (External add input (EXT ADD
IN)”, cf.
Operation:
① Press the
SYSTEM
key, then use the and keys to produce the following display
(EXT-ADD flashes).
ＯＦＦ ＯＮ
ＳＹＳＴＥＭ：
3
ＥＸＴ－ＡＭ ＥＸＴ－ＡＤＤ ФＳＹＮＣ
4
② Press the
ENTER
key, then use the and keys to produce the following display (ON
flashes).
ＯＦＦ ＯＮ
ＳＹＳＴＥＭ：
3
ＥＸＴ－ＡＭ ＥＸＴ－ＡＤＤ ФＳＹＮＣ
4
