3.3 Basic operation
WF1946B
3-33
Output on/off
Output on/off setting is described.
Operation:
① Press the
ON/OFF
CH 2 OUT
CH 1 OUT
ON/OFF
,
key. The setting alternates between on and off each time the key is pressed.
The lamp lights when on, extinguishes when off.
Other:
Except when the channel mode is DIFF, each channel operates independently. In the DIFF mode,
the channel outputs are coupled (i.e., by operating either CH1 OUT or CH2 OUT, both channel
outputs are set on/off).
