3.3 Basic operation
WF1946B
3-30
 Amplitude setting (
ENTRY
→
AMPTD
)
Amplitude (AMPTD) setting is described.
Operation:
The amplitude can be set by two methods.
(1) Keypad
Convenient when the amplitude has been determined beforehand.
For example, set 2 Vp-p as follows.
① Press the
ENTRY
key, then the
AMPTD
key.
The following display is produced.
Amplitude
ＡＭＰＴＤ ０．１０００ Ｖｐーｐ
１．０００００００００ｋＨｚ Ｏ＋０．００００Ｖ ／ＯＰＥＮ
Frequency DC offset
② Press the 2 key, then the
ENTER
key.
To correct an entry, press the
BS
key before pressing
ENTER
key.
③ This completes setting, afterwards, press the
EXIT
key.
(2) Modify dial
The amplitude can be changed continuously.
① Press the
ENTRY
key, then the
AMPTD
key.
② Select the digit to be changed with the
and keys.
③ Turn the
MODIFY
dial to set the flashing digit.
④ After setting, press the
EXIT
key to release the setting mode.
Other:
・ When the oscillation mode is DC, the amplitude cannot be set.
・ Units other than Vp-p can also be set.
“5.2 Units (■Amplitude units change)”, cf.
・ Can also be set by waveform high level and low level.
“5.1 Convenient Settings (■Amplitude and DC offset setting by high and low level)”, cf.
