3.3 Basic operation
WF1946B
3-22
 Channel modes and settings
The channel modes and setting limits are indicated in the following table.
○： Independent setting
△： Both channel settings are the same.
▲： Frequency difference (ΔFREQ) and frequency ratio (RATIO) relationships are maintained.
×： Not settable
*2: Gated sweep mode not selectable
*3: LOG sweep function not selectable
*4: Only CH1 usable for TRIG/SWEEP IN and SWEEP PAUSE IN
*5: When the oscillation mode is sweep or modulation, FREQ indicated the type is frequency and OTHER
indicates other than this.
*6: Control operation is common between channels.
Channel mode [2PHASE] [2TONE] [RATIO]
[INDEP] FREQ other FREQ other FREQ other [DIFF]
Key operation
Menu name
*5 *5 *5 *5 *5 *5
Note
MODE→NORMAL ○ △ ○ △ ○ △ ○ △
MODE→BURST ○ × × × × × × ×
TYPE ○ × × × × × × ×
SOURCE ○ × × × × × × × SOURCE other than TYPE=BURST
INT/EXT ○ × × × × × × ×
INT RATE △ × × × × × × × RATE is internal trigger period
INT ↑↓ ○ × × × × × × ×
EXT ↑↓ ○ × × × × × × ×
EXT CH ○ × × × × × × ×
DELAY ○ × × × × × × × When TYPE=TRIG
MARK ○ × × × × × × × When TYPE=BURST and TRIG
SPACE ○ × × × × × × × When TYPE=BURST
STOP-LEVEL ○ × × × × × × ×
OPER-COMMON △ × × × × × × × Both channels BURST and same TYPE
MODE→SWEEP ○ △ ○ △ ○ △ ○ △
TYPE ○ △ ○ △ ○ △ ○ △
SOURCE ○ △ ○ △ ○ △ ○ △ SOURCE other than MODE=CONT
INT/EXT ○ △ ○ △ ○ △ ○ △
INT RATE △ △ △ △ △ △ △ △ RATE is internal trigger period
INT ↑↓ ○ △ ○ △ ○ △ ○ △
EXT ↑↓ ○ △ ○ △ ○ △ ○ △
EXT CH ○ CH1*4 ○ CH1*4 ○ CH1*4 ○ CH1*4
MODE ○ △*2 ○*2 △*2 ○*2 △*2 ○*2 △*2
FUNCTION ○ △ ○ △*3 ○*3 △ ○ △
START ○ △ ○ ▲ ○ ▲ ○ △
STOP ○ △ ○ ▲ ○ ▲ ○ △
TIME ○ △ ○ △ ○ △ ○ △
STOP-LEVEL ○ × × ○ ○ × × × When MODE=GATE
CENTER ○ △ ○ ▲ ○ ▲ ○ △
SPAN ○ △ ○ △ ○ ▲ ○ △
MARKER ○ ○ ○ ○ ○ ○ ○ △
MKT→CTR ○ △ ○ △ ○ △ ○ △
Continued next page
