3.3 Basic operation
WF1946B
3-34
Operation tree
ON/OFF
CH 2 OUT
CH 1 OUT
ON/OFF
,
Output on/off
CHANNEL MODE
Channel mode [INDEP/2PHASE/2TONE/RATIO/DIFF]
CH 1/CH 2
Channel selection [CH 1/CH 2/BOTH CH1/BOTH CH2]
CH 1/CH 2
Oscillation mode
NORMAL
/
BURST
/
SWEEP
/
MODU
/
NOISE
/
DC
BURST
Menu
TYPE (Burst type) [BURST/TRIG/GATE/T-GATE]
SOURCE (Trigger/gate source selection)
DELAY (Trigger delay) * For TYPE: TRIG
MARK (Number of cycles signal present) * For TYPE: BURST/TRIG
SPACE (Number of cycles signal not present) * For TYPE: BURST
STOP-LEVEL (Stop level)
OPER-COMMON (Simultaneous operation of both channels)
* When the same TYPE is set for both channels
BURST
Operation
MAN TRIG
