NF WF1946B - Fixed Frequency Ratio (RATIO)

5.5 Other settings
WF1946B 5-27
 Fixed frequency ratio (RATIO) (
CHANNEL MODE
: RATIO)
Following is a description of the ratio channel mode whereby a fixed frequency ratio is maintained
between the frequencies of CH1 and CH2 (or vice versa).
In this mode, if the frequency of either channel is changed, the frequency of the other channel is
automatically changed to maintain the fixed ratio.
Operation:
(1) Set the channel mode to ratio
① Press the
CHANNEL MODE
key, then the and keys to produce the following display (RATIO
flashes).
3
ＲＡＴＩＯ ＤＩＦＦ
ＳＥＬＥＣＴ ＣＨＡＮＮＥＬ ＭＯＤＥ
② Press the
ENTER
key to select this channel mode.
(2) Set the frequency ratio between CH2 and CH1.
① Press the
ENTRY
key, then the
RATIO
key.
CH 1 CH 2
Ｒ ００００００１：００００００１
１０００．０００００００Ｈｚ ０．１０００Ｖｐ－ｐ ／ＯＰＥＮ
② Select the affected channel with the
and keys, then set the frequency ratio with the
keypad or
MODIFY
dial.
③ Press the
EXIT
key once to release the setting mode.
Other:
• During ratio, the frequency resolution = 10 nHz × set ratio.
• If the channel mode is set to the fixed frequency ratio (RATIO), the frequency of CH2 changes
according to the frequency ratio (RATIO).
