NF WF1946B - External am (EXT-AM)

5.4 External Input
WF1946B 5-17
 External AM (EXT-AM) (
SYSTEM
: EXT-AM)
Operation to modulate the 1946B output with an external AM signal is described. The external signal is
applied to the rear panel EXT AM IN connector.
For details on connectors, “3.2 Input and output connectors (External AM input (EXT AM
IN)”, cf.
Operation:
① Press the
SYSTEM
key, then use the and keys to produce the following display
(EXT-AM flashes).
ＯＦＦ ＯＮ
ＳＹＳＴＥＭ：
3
ＥＸＴ－ＡＭ ＥＸＴ－ＡＤＤ ФＳＹＮＣ
4
② Press the
ENTER
key, then use the and keys to produce the following display (ON
flashes).
ＯＦＦ ＯＮ
ＳＹＳＴＥＭ：
3
ＥＸＴ－ＡＭ ＥＸＴ－ＡＤＤ ФＳＹＮＣ
4
Other:
• AM appears at the head of the display when external AM is on.
１０００．００００００００Ｈｚ
ＡＭ Ａ０．１０００Ｖｐ－ｐ Ｏ＋０．００００Ｖ ／ＯＰＥＮ
