8-12 WF1946B
8.5 Remote control
z GPIB interface
GPIB function
Use code
Address
Output driver
GPIB parameters
Cancellation of remote state
Connector
SH1 All source handshake functions
AH1 All acceptor handshake functions
T6 Basic talker, serial poll, talker release by MLA
L4 Basic listener, listener release by MTA
SR1 All service request functions
RL1 All remote/local functions
PP0 No parallel poll functions
DC1 All device clear functions
DT1 All device trigger functions
C0 No controller functions
ISO 7 bit codes (ASCII code)
0 to 30 (set from panel)
DIO1-8, NDAC, NRFD and SRQ : Open collector
DAV and EOI : three state
GPIB address (0 to 30), delimiter in transmission (CR/LF+EOI,
CR+EOI, LF+EOI)
Remote state can be canceled by LOCAL key.
(Except for Local Lockout)
Rear panel, IEEE 488 (24-pins) connector
z USB interface
USB1.1 full speed
