WF1946B
2-8
2.4 Conformable standards
The WF1946B conforms to the following standards.
Safety: EN 61010-1: 2001
EMC: EN 61326: 1997/A1: 1998/A2: 2001
However, the performance criteria for the following standards are as follows:
EN61000-4-2(1995):C
EN61000-4-4(1995), EN61000-4-5(1995), EN61000-4-11(1994):B
The phase synchronization (φSYNC) operation may be required because the phase difference
between channels is caused by the electrostatic discharge.
The following cables are used for the test of EN 61326: 1997/A1: 1998/A2: 2001
• Power cable : Accessory
• Signal cables : Coaxial cable with BNC connectors, 1 m (3D-2W or RG-143B/U or RG-223/U)
• GPIB cable : Shielded cable, 1 m (DDK: 408JE-101)
