3.1 Panel description
WF1946B
3-3
Front panel
Lamp lights to indicate output range.
When the range is set for automatic switching, the AUTO lamp
lights (page 3-24).
The OVER lamp flashes when the output voltage exceeds the upper
limit (page 3-5).
Output waveform on/off.
Key lamp lights when on, extinguishes when off.
Displays frequency, amplitude, offset and
load impedance settings, in addition to
information to assist when setting.
Lamps light to indicate present oscillation
mode and waveform selection.
Oscillation mode
selection (page 3-25)
Frequency and amplitude setting
(pages 3-29 to 3-30) setting (page3-22)
Selects channel mode.
Lamp above key indicates present
selection (see page 3-20).
Waveform select
(page 3-26)
Selects channel for display and setting.
Lamp above key indicates present selection.
Power on/off. Depress for power on,
press and release to raised position for
power off.
Setting initialize (page 3-16), output range setting (page 5-18), user
unit setting (page 5-9)
Trigger/sweep input
connector (page 3-9)
Sync signal output
connector (page 3-6)
Waveform output
connector (page 3-5)
Key button, top or bottom lamps light
only for operable keys.
When MODIFY lamp lights, turn dial to
set values or parameters.
Press to enter, e.g., a numerical
input.
Return to the previous step.
UNDO key
a
e 5-21
Memory save, recall, etc.
(pages 5-13 to 5-15)
