8.3 Other functions
8-6 WF1946B
z Sweep
Sweep items
Setting items
Sweep functions
Sweeping time
Range
Resolution
Sweep trigger
Sweep trigger period
Trigger source
External trigger
Polarity
Input connector
Minimum pulse width
Trigger delay
Frequency, phase, amplitude, DC offset, and duty ( duty variable)
Sweep start/stop or sweep center/span
Sweep marker, substitute sweep center for sweep marker
Sweep start and stop conditions
Continuous / single / gated sweep
LIN/LOG (LOG is available frequency only)
/ / /
1 ms to 10000.000 s (during 2 channel independent, sweep or
modulation of only one of the channels)
2 ms to 10000.00 s (other times)
1 ms
Indicates start of single / gated sweep.
100 ms and more (If applying less than 100 ms, trigger is at 100
ms intervals).
Selectable internal trigger oscillator or external trigger input.
Also, applicable from panel keys and via remote control (GPIB or
USB)
The CH1 external trigger can also be selected for the CH2 trigger
source.
Selectable rise/fall.
Front panel, BNC receptacle (TRIG/SWEEP IN)
200 ns
2 ms
Internal trigger oscillator period
Range
Resolution
Oscillation stop level
Range
Resolution
1 µs to 100.0 s
4 digits at 1 ms and more, 1 µs at less than 1 ms.
On/off setting effective during gated sweep.
(However, ineffective and fixed at off if the sweep item is duty)
Off: stop at set phase.
On: stop at set stop level.
−100.00 %（maximum negative output) to +100.00 % (maximum
positive output)
0.01 %
