4.4 Connecting to the Part handler (Handler Interface)
4-20 ZM2371/ZM2372
Extending the Bin number of primary parameter
The initial value of class number of primary parameter is “9”, but can be expanded to “14”.
“Bin extension setting menu is as follows:
BIN10-14 Output: OFF Current setting
0)OFF=PHI,PLO 1)ON=BIN10-14 Options
OFF The signals of “BIN10 to BIN14” are not outputed (max 9-class).
When the primary parameter is outside the range, PHI or PLO signal is
outputed.
ON The signals of “BIN10 to BIN14” are outputed (max 14-class).
Even if the primary parameter is outside the range, both PHI and PLO
signal are not outputed.
If a setting is made or the EXIT operation is performed, one-previous menu comes back.
In case that the signals of BIN10 to BIN14 are not outputted, even if setting is made so
that sorting for those BINs will be conducted, sorting for BIN10 to BIN14 is not
conducted.
Setting the Trigger polarity
You can select which of rising edge and falling edge of trigger signal is used to start
measurement.
“Polarity setting menu of trigger input signal is as follows:
TRIG Polarity:Negative Current setting
0)Negative 1)Positive Options
Negative Falling edge (H→L) of trigger signal is used to trigger.
Positive Rising edge (L→H) of trigger signal is used to trigger. (initial value)
If a setting is made or the EXIT operation is performed, one-previous menu comes back.
The Trigger polarity cannot be selected in Remote control.
Selecting the functions of memory selection signal
You can select the target for restoring from the setting/correction value memory by the input
signal to the handler interface.
“Memory selection signal setting menu is as follows:
Handler Recall Function:Setting Current setting
0)Setting 1)Correction 2)Both Options
Setting Recalls only the setting from the specified memory (initial value)
Correction Recalls only the correction value from the specified memory
Both Recalls both setting and correction value from the specified memory.
If a setting is made or the EXIT operation is performed, one-previous menu comes back.
