5.6 Command Explanation
5-64 ZM2371/ZM2372
[:SENSe][:FIMPedance]:RANGe:AUTO {ON|OFF|1|0}
[:SENSe][:FIMPedance]:RANGe:AUTO?
Description: Sets/queries automatic switching of measurement range.
Parameters: {ON|1} Enables automatic switching of measurement range.
{OFF|0} Disables automatic switching of measurement range, and
fixes the range (HOLD).
Setting example: :RANG:AUTO ON
Sets so as to enable automatic switching of measurement range.
Response: {1|0}
Query example: :RANG:AUTO?
Response example: 1
Automatic switching of measurement range is enabled.
Remarks: Automatic switching of measurement range is automatically disabled if
specific range is set by panel operation or remote control.
[:SENSe][:FIMPedance]:RANGe[:UPPer] <range>
[:SENSe][:FIMPedance]:RANGe[:UPPer]?
Description: Sets/queries the measurement range. The range is specified in
impedance.
Parameters: <range>
{numeric value, range 100E-3|1|10|100|1E+3|10E+3|100E+3|1E+6,
unit: }.
As suffix, M (10
-3
), K (10
+3
), MEG (10
+6
) can be used.
As unit, OHM can be used. MAX / MIN can be used.
Parameter example: 10K (= 10E+3), 100OHM (= 100).
If an out-of-range value is set, it becomes minimum or maximum value.
If an arbitrary value is given, the range suitable for measuring that
value is set.
Range

Measurement range
1M≦Parameter

1M
100k≦Parameter< 1M

100k
10k≦Parameter< 100k

10k
1k≦Parameter< 10k

1k
10 < Parameter< 1k

100
1 < Parameter≦10

10
100m < Parameter≦1

1
Parameter≦100m

100m
Setting example: :RANG 10E+3
Sets the measurement range to 10k.
Response: {numeric value, format NR3}
Query example: :RANG?
Response example: +1.00000E+04
The measurement range is 1.00000E+04  (10k).
