4.3 Sorting the Part (Comparator)
4-9 ZM2371/ZM2372
Sorting the primary and secondary parameters with the deviation
When the primary and secondary parameters are display format of deviation or deviation%,
they are sorted by the values of deviation or deviation%.
The comparison format of primary parameter can be set in the comparator setting menu.
Since the comparison format (=Display format) and the reference value for obtaining a
deviation are common to both display and comparator, they may be set for either display or
comparator.
Since it is impossible to set the comparison format of secondary parameter in the
comparator setting menu, alternatively use the setting for display format.
Select the DEV with the comparator setting menu, the primary parameter deviation
comparison menu for the comparator is displayed.
DEV: The primary parameter deviation comparison menu is as follows:
Comparison Reference value for
format deviation comparison
Deviation:ABS REF:+1.23456µF Current setting
0)ABS 1)DEV 2)DEV% 3)REF Options
ABS Conducts the comparison according to the original
measured values. (Initial value)
DEV Conducts the comparison according to the
deviation from the reference values. Comparison format
DEV% Conducts the comparison according to the
deviation% value from the reference values.
REF Displays the primary parameter reference value setting menu for the
comparison of deviation.
Select one of ABS, DEV or DEV% as the comparison format by the numeric key.
To display the deviation or deviation%, previously set the reference value.
If a setting is made or the EXIT operation is performed, one-previous menu comes back.
REF: The deviation comparison of primary parameter reference value setting menu is as
follows.
DEV Reference:+1.23456µF Current setting
±(0.0000p to 999999M) Range of settable values
Enter the numeric value, and press the input of exponential part
_
EXP
_
+ [µ] keys for
instance.
If a setting is made or the EXIT operation is performed, the measurement screen comes
back.
