DISPLAY AND MENU OPTIONS
Table 10. Smart DC Controller - Installer Menu Functions
Ref.
No.
User Menu
Display
Setting Options
(Bold = Factory
Settings)
Menu Tasks and Explanations
Associated
DC
Controller
Display
Connections
20
EO 0 (STOP ONLY)
EYE OPEN LOGIC
0 = Open eye
stops only
1 = 2s reverse to
close
Default setting is non-reversal if
open photo eye is triggered while
opening. A setting of 1 causes
gate to reverse travel and close
for two seconds if triggered while
opening.
Sensor
Common
Sensor Input
21
GR 0 (FULL OPEN)
GATE EDGE LOGIC
0 = Edge reverses
full open
1 = 2s reversal only
Default setting is a full-open
reversal if gate edge is triggered
while closing. Optional setting of
1 causes gate to reverse for two
seconds if triggered while closing.
Sensor
Common
Sensor Input
22
SR 1 REVERSE 2S
IES SENSOR LOGIC
0 = IES reverses full
open
1 = 2 second
reversal only
Default setting is a two-second
duration reversal if inherent sensor
is triggered. Optional setting of 0
will cause gate to reopen fully if
triggered while closing.
(N/A)
23
PC 1 NO CONTACT
PHOTO EYE OUTPUT
0 = Normally Open
PE output
1 = Normally Closed
(supervised)
This menu item only appears when
UC is set to 4. Default setting is
photo eyes with Normally Close
outputs. Optional setting 0 requires
a Normally Open (NO) output.
When set for NC, connection is
monitored and any short circuit
fault will generate a FAULT 2 alert
which requires a STOP or RESET
button press to re-enable gate
operation.
Photo eye
connections:
Sensor
Common
Sensor Input
+24V
24
GC 1 NO CONTACT
GATE EDGE OUTPUT
0 = Normally Open
Edge
1 = Normally
Closed
This menu item only appears when
UC is set to 4. Default setting is
edge sensor with Normally Closed
(NC) output. Optional setting of 0
requires an (NO) output.
Sensor
Common
Sensor Input
