DISPLAY AND MENU OPTIONS
Table 10. Smart DC Controller - Installer Menu Functions
Ref.
No.
User Menu
Display
Setting Options
(Bold = Factory
Settings)
Menu Tasks and Explanations
Associated
DC
Controller
Display
Connections
25
S1 0
SENSOR #1 TYPE
0 - disabled
1 - (NOT USED)
2 - (EYE CLOSE)
3 - (EDGE CLOSE
4 - (EYE OPEN)
5 - (EDGE OPEN)
6 - (EDGE BOTH)
7 - (EYE BOTH)
UL 325 - 2018 sensor input setting
for external entrapment protection
sensor monitoring. All three sensor
types must be configured to a
non-zero number before the gate
operator will move the gate. Edge
Both is only available in Swing
Gate operator types. Eye Both
is only available in Slide Gate
operator types.
26
S2 0
SENSOR #2 TYPE
Same as Sensor 1 Same as Sensor 1
27
S3 0
SENSOR #3 TYPE
Same as Sensor 1 Same as Sensor 1
28
DT 0 FREE EXIT
DISABLE FUNCTION
0 = Disable Free
Exit
1 = Disable Close
Timer
Congures BLOCK EXIT input to
disable either Free Exit Detector
function or, alternately, Close
Timer function. Default setting
disables free exit detector.
NOTE: Free exit is disabled
when gate is at its closed limit.
If closed limit is not tripped, free
exit continues to work normally.
BLOCK EXIT
COM
29
OR 1 REVERSE
OUTSIDE OBS LOOP
0 = Pause closing
only
1 = Enable reverse
to open
Default is for full reversal when
Outside Obstruction Loop is
triggered while closing. A setting
of 0 causes gate to only pause
when triggered. Gate closure
continues as soon as loop is clear
again.
OUTSIDE OBS
LOOP COM or
Hy5B
SlideSmart HD Programming and Operations
5959
MX4435 Rev.G ©2022
