DISPLAY AND MENU OPTIONS
Table 10. Smart DC Controller - Installer Menu Functions
Ref.
No.
User Menu
Display
Setting Options
(Bold = Factory
Settings)
Menu Tasks and Explanations
Associated
DC
Controller
Display
Connections
32
RL 1 0 DISABLED
RELAY 1 LOGIC
0 = default
1 to 45 available
Configures function of the
user 1 output relay, which is an
electromechanical relay. It has
capacity to switch, both AC and
DC and can be used for high
voltage and/or high current loads.
Connect devices directly to the top
of relay: COM plus NO and NC
contacts. Up to 45 optional relay
functions exist.
See "Figure 62. Setting the User
Relay Function in the Installer
Menu" on page 83.
User 1 Relay
33
RL 2 1 CLOSE LIMIT
RELAY 2 LOGIC
0 = default
1 to 45 available
Congures function of user output
relay, which is an electronic relay
with capacity for switching a DC
load only. The User 2 Relay is
limited to 48 Volts DC and 4A
maximum load. Up to 45 optional
relay functions exist.
See "Figure 62. Setting the User
Relay Function in the Installer
Menu" on page 83.
User 2 Relay
34
RL 3-10 1 CLOSE LIMIT
RELAY 3-10 LOGIC
0 = Disabled
Up to 45
Similar to Relay 1 Logic.
NOTE: The Hy8Relay™ module
option can be purchased for eight
additional NO relay outputs. Relay
#39 set aside for Factory Use.
User 3 -10
Relay
35
TL 2 (45 SECS)
OPEN TIME ALERT
0 = 0 seconds
1 = 15 seconds
2 = 45 seconds
3 = 75 seconds
4 = 105 seconds
5 = 135 seconds
Adjusts time delay before activating
a user relay. Maximum time setting
is 135 seconds. See "Figure 62.
Setting the User Relay Function in
the Installer Menu" on page 83.
NOTE: This menu controls a user
relay set to Function No. 8
User relays
