The Computer
5-18 Manual # 42-02-1P28 A3
Additional
Features
- Sabbath: Enable (Yes/No) Configures the controller to allow Sabbath Operation.
Sabbath is triggered by spare input SABBATH IN. By default, the car will travel
to the highest unsecured Sabbath Floor and then work its way down stopping at
every unsecured Sabbath Floor. Sabbath Floors are defined in Config 1 > Build-
ing Setup > Floor Eligibilities.
- Sabbath: Start Floor (0-16) (0=None) This floor specifies where a Sabbath trip
shall start. If a Start floor is selected, the car will proceed to this floor before it
starts servicing the building.
- Sabbath: Return Floor (0-16) (0=None) This floor specifies where a Sabbath
trip shall end, after servicing all Sabbath floors. The user can select to end a
Sabbath trip at the last Sabbath floor served or any other floor.
- Sabbath: Pref. Start Dir. (Up, Down, None) Specifies the preferred Sabbath
Operation start direction when Sabbath is activated. Used only if there was no
direction when Sabbath was activated and if a Start Floor was not programmed.
Otherwise, Sabbath will start in the current direction.
- Sabbath: # of trips (0-10) (0=Off) Number of trips before the car returns to
normal group operation between trips. (all floors are served at least once in con-
figured directions)
- Sabbath: Pause Time (0-120 minutes) (0=Off) Specifies the time between
each Sabbath trip during Sabbath operation.
- Sabbath: Door Open Time (0.50-120.00 seconds) Specifies the time to keep
the doors open after answering a Sabbath call.
- Sabbath: DC Warn. Buzr. (0.50-120.00 seconds) Specifies the amount of time
between sounding the door close warning buzzer and closing the doors after
answering a Sabbath call.
- Sabbath: Nudging (Yes/No) Used to close the doors at reduced speed and
torque during Sabbath Operation (needed when the PHE is bypassed via hard-
ware).
- Sabbath: Allow Hall Calls (Yes/No) Used to specify whether a car remains in
service for hall calls during Sabbath trips.
- Sabbath: Allow Car Calls (Yes/No) Specifies whether car calls can be registered
via the COP or other sources during Sabbath trips
- Sabbath: Finish Car Calls (Yes/No) Specifies if all existing car calls should be
answered before a Sabbath trip can be initiated.
- Sabbath: Car Call Lights (Enable/Disable) Specifies whether to disable the car
call buttons light for the during Sabbath trips.
- Sabbath: Door Buttons (Enable/Disable) Specifies whether to disable all COP
door buttons (DCB, DOB, DHOLD) during Sabbath trips.
- Sabbath: Arrival Lanterns (Enable/Disable) Specifies whether to disable the all
car and hall arrival lanterns and gongs during Sabbath trips.
- Sabbath: PI Outputs (Enable/Disable) Specifies whether to disable non-serial
position and direction arrow indicators during Sabbath trips (serial fixtures shall
always remain enabled).
- Sabbath: Override Security (Yes/No) Used to allow secured floors to be ser-
viced during Sabbath trips.
- KEYBOARD CONTROL (KCE): (Yes/No) Set to enable commands from iMonitor
(Recall Command, …).
Table 5.2 Touchscreen Organization and Content
Tab Subtab Description
