The Computer
5-32 Manual # 42-02-1P28 A3
OPENING F/R The doors are opening or attempting to open. See output DOF/DOFR
OVERLOAD Car is in Overload Status
OVERLOAD2 Car is in Overload 2 Status
PI OUTPUT (1-8) Position Indicators outputs. Fully configurable for standard binary, gray code or one line
per floor. Use dedicated UIO board (s) if more than 8 outputs are needed
PIT FLOOD Pit Flood operation has been activated by the Pit Flood input, which prevents access to
certain floors
SAB ENDED Sabbath Mode has Ended
SAB ON Sabbath Mode is On
SERV IN Car in service on Passenger Mode
SERV OUT Car not in service for hall calls
SHUTDOWN Car shutdown
Table 5.5 Acronym Descriptions and Memory Locations
Acronym Description and Memory Location
NOT USED An available spare input, or output, that has yet to be assigned @ CONFIG 01
2 BUS
Primary 110 VAC bus with respect to 1 bus (GND), View status @ MOTION DIAG > MOTION
Inputs 2BUS.B, or MOTION Flags 2 BUS
2 STOP FLG
Car is configured for 2 stop operation. When a car is set to be a two stop installation, CON-
FIG 01 > Building Setup parameters must be properly set and DLMS (Door Lock Middle
String) connection on SCE-HVI board must not be connected. View Status @ PLD DIAG >
PLD Flags 2 STOP FLG
2LS BUS
110 VAC bus, when active, means that both locks and safeties are active. View @ PLD DIAG
> PLD Inputs, scroll to M2L, or MOTION DIAG > MOTION Inputs, M2L.B > M2L.P
2MV BUS
110 VAC bus supply from Fuse F2MV, monitoring source @ MOTION DIAG > MOTION Inputs
M2MV.B
SC-3HN
The serial node board connected to hall call push button fixtures (hall call boxes). Use Status
Info Tab and then Hall Bus Inventory to inventory and test node boards used in hall call
boxes
ABD
Access Bottom Down input from access key switch at bottom floor, view @ MOTION DIAG >
MOTION Inputs ABD.B, ABD.P, also view @ PLD DIAG > PLD Inputs ABD
ABU
Access Bottom Up input from access key switch at bottom floor, view @ PLD DIAG > PLD
Inputs ABU
ADA
American with Disabilities Act. Denotes special signals, timers, devices, etc. to accommo-
date disabled access
APS Auxiliary Power Supply: Typically supplied by a HAPS unit
ATD Access Top Down @ PLD DIAG > PLD Inputs ATD
ATU Access Top Up. Key switch access @ PLD DIAG > PLD Inputs ATU
CC Car Call @ CAR DIAG> CAR FLAGS, view flags starting with CCF (Car Call Front)
CC ENBLx
Car Call Enable, input used to enable a secured car call. View status @ SYSTEM I/O > PRO-
GRAMMED INPUTS
CCF Please see various CCF flags @ CAR DIAG > CAR FLAGS
CCT
Car Call Dwell Time. Time for doors to remain open after a call has been answered. @ CAR
DIAG > Door Dwell Times > Car Call
CDB
Car Door Bypass input from switch @ MOTION DIAG > MOTION Inputs and also PLD DIAG >
PLD Inputs
Table 5.4 Spare Outputs
Output Description
