The Computer
5-100 Manual # 42-02-1P28 A3
SABBATH NUDGING ENABLED (818) Description: This event is logged at start and end of Sabbath operation
only (to avoid filling the log with the nudging events). The event indicates
that the Sabbath operation nudging option is enabled and that doors will
close at reduced speed and torque while on Sabbath operation.
Car actions:
Doors will close at reduced speed and torque during Sabbath operation.
Troubleshooting:
1. Check the related SABBATH: NUDGING option and make sure it is set
as required.
SAFH INPUT LOW (140) Description: The hoistway safety string input is low. Car will perform an
emergency stop or, if at a floor, will not move. Doors remain as they are.
System Verifies:
- SAFH Input is low
- SAFC input high
Troubleshooting:
If in error verify input and input devices mechanically and electrically.
SAFETY DROPPED (485) Description: The Safety Circuit has been open due to a safety fault.
Troubleshooting:
Check fault diagnostics for SAFC and SAFH.
SAVING DISPATCH PARAMS (275) Description: Appears when dispatching related parameters are being
saved. Informational.
SAVING OTHER CAR PARAMS (276) Description: Appears when parameters communicated by other car in
duplex pair are being saved. Informational.
SD CARD ERROR (176) Description: The micro-SD card used for event logging is damaged or
improperly formatted. Remove and reseat the card. Replace the card with a
new card of like capacity if required. Cannot be bypassed.
SD FILE SYSTEM ERROR (346) Description: System has determined that data sent to SC card on HC-
MPU-2-TS is invalid.
Troubleshooting: Remove and reinsert SDRAM card and repeat file trans-
fer.
SE BYPASS FRONT (33)
SE BYPASS REAR (778)
Description: The door safe edge input has been bypassed. See SE Fail.
Fault-bypassed in Construction.
System Verifies: - Door Flags = Safe Edge Bypassed
Troubleshooting:
Verify no Safe Edge input programmed if safe edge is not used.
See SE Fail (Config 01 > Configure Spare Inputs).
SE FAIL FRONT (34)
SE FAIL REAR (779)
Description: The door safe edge has failed. Issued when the safe edge has
been continuously activated for a predetermined period while the doors are
fully closed. Fault-bypassed in Construction.
System Verifies: - Door Flags = Safe Edge Failed
Troubleshooting:
Check for obstruction.
Check that input is properly wired and programmed (Config 01 > Configure
Spare Inputs).
SIMPLEX CAR ID ERROR (347) Description: Generated if Number of Cars = 1 and Car ID is anything other
than 1.
Table 5.10 Touch Screen Event Listings
Event Description
