The Computer
5-102 Manual # 42-02-1P28 A3
STUCK F. DOOR ZONE FAULT (192)
STUCK R. DOOR ZONE FAULT (810)
Description: Door zone did not go low during run. Fault-bypassed in Con-
struction/Inspection.
Troubleshooting:
Verify activity.
Check wiring.
Verify DZ flag activity at Utilities > Landing System Utilities > Landing Sys-
tem View to see that DZ turns off when car is between floors.
STUCK DOWN HALL CALL F. (256)
STUCK DOWN HALL CALL R. (258)
Description: System has detected a sticking down hall call button.
STUCK LEVELING FAULT (194) Description: Leveling signal did not transition low at end of run. ULM and
DLM are both active. Fault-bypassed in Construction/Inspection.
Troubleshooting:
Verify, UTILS > Landing System View > ULMF or DLMF.
Verify landing system function and wiring.
STUCK PHE2 FRONT (840)
STUCK PHE2 REAR (843)
Description:
The auxiliary (front/rear) photo eye input has been continuously activated
for a user defined time.
Car actions:
None if the option to bypass a stuck photo eye is disabled. Otherwise, the
photo eye is rendered inoperative and the doors close. Doors close at
reduced speed if no other reopening devices are available.
Troubleshooting:
1. Check the auxiliary photo eye input and related circuitry.
2. Check the related stuck photo eye timer and option.
3. Fault is cleared when the door open button is deactivated.
STUCK PHOTO EYE FRONT (136)
STUCK PHOTO EYE REAR (781)
Description: Photo eye input continuously active. If Bypass Stuck PHE
(Config 01) is enabled, the controller will ignore the PHE and close the
doors after the Stuck PHE Timer elapses or when the Car Delayed timer
expires, whichever comes first. Fault-bypassed in Construction/Inspection.
System Verifies:
- Door Flags = Stuck Photo Eye Timer Elapsed
- Door Flags, Photo Eye Bypassed and Photo Eye Failed are not true.
Troubleshooting:
Verify PHE status, System IO, Programmed Inputs.
If no PHE is installed, PHE input should not be programmed.
Verify function of PHE device.
STUCK SAFE EDGE FRONT (137)
STUCK SAFE EDGE REAR (782)
Description: Safe edge input continuously active. If Bypass Stuck Safe
Edge (Config 01) is enabled, the controller will ignore the SE and close the
doors after the Stuck SE Timer elapses or when the Car Delayed timer
expires, whichever comes first. Fault-bypassed in Construction/Inspection.
System Verifies:
- Door Flags, Stuck Safe Edge Timer = Elapsed
- Door Flags Safety Edge Bypassed and Safe Edge Failed are not true.
Troubleshooting:
Verify Safe Edge status, System IO > Programmed Inputs.
If no Safe Edge is installed, input should not be programmed.
Verify function of Safe Edge device.
Table 5.10 Touch Screen Event Listings
Event Description
