PC Board Quick References
Manual # 42-02-1P28 A3 6-23
Call Inputs and Outputs
Table 6.19 HC-UIO-2 Board Call Assignments
Board
ID
Switch Setting
1 2 3 4 5 6
I/O 1 to I/O 16
00 Off Off Off Off Off Off
HC-UIO-2 boards numbered 00 through 31 are used for call related I/O.
The associated switch setting is shown to the left. Terminal assign-
ments, beginning with terminal I/O 1 through I/O 16 on board 00, fol-
lowed by terminal I/O 1 through I/O 16 on board 01, etc., are made in
the following order:
nn = TOP FLOOR OPTION
• PIs PI1 - PI(nn)
• Front car calls 101 - 1(nn)
• Rear car calls 101R - 1(nn)R
• Front down hall calls 502 - 5(nn)
• Front up hall calls 601 - 6(nn-1)
• Rear down hall calls 502R - 5(nn)R
• Rear up hall calls 601R - 6(nn-1)R
HC-UIO-2 board terminal assignments are determined by the settings
of the following CONFIG 01>BUILDING SETUP MENU
:
• BOTTOM FLOOR
• TOP FLOOR
• FLOOR nn OPENING (NONE/FRONT/REAR/BOTH 1-32)
And the following CONFIG 03>BUILDING SECUTRITY menu:
• CALLS ON UIO BOARD
•UIO POSITION INDICATORS
The status of these terminals (ON or OFF can be determined by observ-
ing the indicators on the HC-UIO-2 boards).
01 On Off Off Off Off Off
02 Off On Off Off Off Off
03 On On Off Off Off Off
04 Off Off On Off Off Off
05 On Off On Off Off Off
06 Off On On Off Off Off
07 On On On Off Off Off
08 Off Off Off On Off Off
09 On Off Off On Off Off
10 Off On Off On Off Off
11 On On Off On Off Off
12 Off Off On On Off Off
13 On Off On On Off Off
14 Off On On On Off Off
15 On On On On Off Off
16 Off Off Off Off On Off
17 On Off Off Off On Off
18 Off On Off Off On
Off
19 On On Off Off On Off
20 Off Off On Off On Off
21 On Off On Off On Off
22 Off On On Off On Off
23 On On On Off On Off
24 Off Off Off On On Off
25 On Off Off On On Off
26 Off On Off On On Off
27 On On Off On On Off
28 Off Off On On On Off
29 On Off On On On Off
30 Off On On On On Off
31 On On On On On Off
