PC Board Quick References
Manual # 42-02-1P28 A3 6-27
•Motion CAN Baud Rate
• Switch 7 OFF: 250k (default)
• Switch 7 ON: 500k
• Motion Unused Switches
• Switches 4 and 6 are unused and should be left in the OFF position.
• 24V Power: The 24V power supply from the cartop box must be connected to the 24V IN
connector J35 on the first ICE-COP-2 board. If additional boards are used they are con-
nected to 24V. Load connections (power source for buttons and switches in the car panel)
can be made to any of the boards at the 24V CUSTOMER LOAD SUPPLY connector as
long as load current at any one board is not more than 4A.
• CAN Bus Termination: Jumper JP1 terminates the CAN bus in the correct impedance
for CAN signal transmissions.
• If more than one COP board is used, ONLY the last board in the CAN string should
have jumper JP1 plugged in. (If there is only one COP board, it must have JP1 plugged
in.)
