NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 28
CHAPTER 2 MAINTENANCE
1 SERVICING
APRIL 15, 2012
Gearshift Cable
Failure to follow the shift cable precautions following can
result in serious injury or equipment damage.
1. Disconnect the shift cable from the shift control on the transmission.
(Driver’s side of transmission).
2. Place gearshift lever on dash in N (neutral).
3. Move the control lever on transmission to the rearmost position detent.
Move the control lever on transmission ahead 2 detents. This is neutral.
4. Adjust cable length by turning clevis in or out until clevis will slide through
clevis and shift lever without movement of shift lever or control lever.
5. Move control lever through the entire shift range one position at a time,
checking shift lever detent at each position.
6. Tighten the clevis lock nut. Install the clevis and a new self-locking nut.
