EV Series Automated Dispensing Systems
74
Fill Area: 2. Circle
This command lls the dened area by moving the tip along a spiral path from the outside of the circle to the center. After entering
a Fill Area Circle command, jog the tip to a point on the outside limit of the circle to be lled and enter that location as a Line Start
point. Then jog the tip directly across to the center of the circle and enter that location as a Line End point.
Line End
Line Start
Fill Area
EXAMPLE: if a Width of 5 mm is entered, the tip makes the following path:
Width = 5 mm
Fill Area: 3. Rectangle (Outer to Inner)
This command lls the dened area by moving the tip along a square, spiral-shaped path from the outside of the rectangle to the
center. After entering a Fill Area Rectangle command, enter a Line Start point at the top left corner of the area to be lled and a
Line End point at the bottom right corner of that area.
Line Start
Line End
Fill Area
EXAMPLE: If a Width of 5 mm is entered, the tip makes the following path:
Width = 5 mm
Appendix A, Command Function Reference
(continued)
