Simple SIP DECT configuration 157
6 Select the check box for VTRK and enter the VTRK zone
number, for example 1, for ZONE.
7 Select the Node ID of the signaling server for NODE.
8 Select SIP for PCID.
9 Select the check box for ISDN.
10 Select ISLD for MODE.
11 Select the DCH created previously, for example 5.
12 Select SL1 for IFC and 1, for example, for the Private Network
Identifier (PNI).
13 Select the check box for NCNA and INAC.
14 Select CDP for CTYP.
15 In Network Options select ESN5 for SIGO.
16 Click Submit.
--End--
Adding trunks
To add a trunk using Element manager, complete the following procedure.
Procedure 64
Adding a trunk
Step Action
1 Select System > Core Equipment > Superloops from the menu
list.
2 On Superloops, select 96, for example, for superloop number
and Virtual for type.
3 Click Add and then click Save.
4 Select Routes & Trunks > Routes & Trunks from the menu list.
5 On the Route & Trunks page click Customer: X.
The customer list expands and Route: Z appears.
6 click Add trunks.
The Customer X, Route Z, New Trunk Configuration page
appears.
7 Select 32 for MTINPUT.
8 Select IPTI for TYPE.
9 Select VTRK for XTRK.
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
