76 Site planning
center and the cell boundary, see “Multi cell deployment” (page
76).
10 Choose a position on the floor plan for the cell center that meets
the following requirements.
a is furthest from the critical points and still provides good audio
quality at the critical point,
b complies with the “Rules and guidelines to locate cell centers”
(page 35), and
c is in the coverage area.
11 Mark each cell c on the floor plan and label them 1C1 and 1C2.
12 Place the deployment tool at each cell center to find the cell
boundary and mark it on the floor plan.
13 Repeat this technique for the remaining coverage area from
the outer extremes of the coverage area toward the center until
the entire floor has been covered. If the cell boundary covers
other critical points, ignore these critical points as you deploy
coverage.
--End--
Multi cell deployment
Use the multi cell technique only if referred here from the double cell
technique. Before beginning this technique, there must be two critical
points that one cell center cannot serve. Using the multi cell technique,
two cell centers, each one serving one of the two critical points, are found,
as shown in Figure 45 "Multi-cell distance" (page 77).
Nortel Communication Server 1000
SIP DECT Fundamentals
NN43120-123 01.07
6 January 2009
Copyright © 2008-2009 Nortel Networks
.
