7. LoosenthescrewsecuringtheUVlampcover(A),andpullthecover
up
(B),thenout(C).
Figure 7-62: Removing the UV lamp cover
8. Pullthelampreflectoroutoftheprintblock.
Figure 7-63: Removing the UV lamp reflector
9. Ontheinsideofthelampreflector,ablackstripcoverspartofthe
reflector.Removethisstripbyslidingitoff.
Figure 7-64: Removing the black strip from the old reflector
10. Discardtheoldreflectorandlamp,butsavetheblackstripsoyoucan
installitinthenewreflector.
