2. Installation
2. Putthebottomsof the anti-tipfeet(both sides)ontheoor,alignthesidestothe
cabinetandtightenthemwiththetwoscrewseach.
Screw hole
Note! • Donottightentheupperscrewholes.
 • Whenyoutightenthebottomscrews,attachtheanti-tipfoottothelocatoin
whereascrewdoesnotincline.

*
 You can attach thescrews toCase1and Case2. As the screw inclines
when you tighten the screw in Case3, lift the anti-tip foot and attach the
screwtoCase2.
Screw hole
Case 1
OK OK NG
Case 2 Case 3
3. Tightentheanti-tipfootcovers(bothsides)andanti-tipfeetwithtwoscrewseach.
4. Aligntheanti-tipfootcover(rear)totherearsideoftheanti-tipfoot.
