Oki Data CONFIDENTIAL
42615101TH Rev.8 198 /
(4) Hold the handle and install the fuser unit on the printer gently.
(5) Move down the fuser unit locking levers (two blue levers) toward the back side and secure
the fuser unit.
Note!
Print Menu map (Chapter 3.6) or blank sheets several times since toner not fused is left
inside the fuser unit after a jammed paper is removed from the fuser unit.
If paper jam error is not corrected after the jammed paper is cleared, clear another jammed paper
following the procedures below.
(1) Touch the screw with a hand to discharge static.
Handle
Fuser unit
locking lever (blue)
To Next Page
