Troubleshooting
SD Module
Abnormal
Normal
Possible Causes
Suggested Action
LED not illuminated
Green solid LED
Green SD card indicator is
enabled and configured
Green blinking LED when
reading or writing a record
The SD module is not present
The SD module is present but not
enabled
The SD module is not formatted for use
• Check if the status indicates one of
the following:
− No Card
− Not Enabled
− Not Formatted
• Insert and enable an SD card.
• If the status does not read “Ready”
on the front panel, format the SD
card from the front panel.
Amber solid LED
The SD card status
indicates “Read Only” or
“No Sys File!” on the
front panel
The SD module is set to the locked
position or was removed, and the
system files were manually deleted
before it was reinserted into the Omni
CPU
• With the SD card inserted:
− Follow the proper eject
procedure from the front panel.
− Remove the SD card and
ensure it is set to the unlocked
position.
− Reinsert the SD card and follow
the Enable procedure from the
front panel.
• It may be necessary to format the
card for it to show the status as
‘Ready’.
Red solid LED
The eject procedure from the front
panel was not followed before
physically removing the SD card.
• Check if the Status indicates
“Improper Eject”.
• Physically reinsert the SD card,
execute the eject procedure from
the front panel, then use the Enable
procedure.
• Format the card if the Status does
not indicate as “Ready”.
