5 Installation
5-28
CJ2 CPU Unit Hardware User’s Manual
z Available Connectors
Use the following connectors when assembling a connector and cable.
CJ-series 32- and 64-point Basic I/O Units with Fujitsu-compatible Connectors
CJ-series 32- and 64-point Basic I/O Units with MIL Connectors
Using User-made Cables with Connector
Applicable Units
Model Specifications Pins
CJ1W-ID231 Input Unit, 24 VDC, 32 inputs 40
CJ1W-ID261 Input Unit, 24 VDC, 64 inputs
CJ1W-OD231 Transistor Output Unit with Sinking Outputs, 32 outputs
CJ1W-OD261 Transistor Output Unit with Sinking Outputs, 64 outputs
CJ1W-MD261 24-VDC Input/Transistor Output Units, 32 Inputs, 32 Outputs
CJ1W-MD231 24-VDC Input/Transistor Output Units, 16 Inputs, 16 Outputs 24
Applicable Cable-side Connectors
Connection Pins OMRON set Fujitsu parts
Solder-type 40 C500-CE404 Socket: FCN-361J040-AU
Connector cover: FCN-360C040-J2
24 C500-CE241 Socket: FCN-361J024-AU
Connector cover: FCN-360C024-J2
Crimped 40 C500-CE405 Socket: FCN-363J040
Connector cover: FCN-360C040-J2
Contacts: FCN-363J-AU
24 C500-CE242 Socket: FCN-363J024
Connector cover: FCN-360C024-J2
Contacts: FCN-363J-AU
Pressure-welded 40 C500-CE403 FCN-367J040-AU
24 C500-CE243 FCN-367J024-AU/F
Applicable Units
Model Specifications Pins
CJ1W-ID232 Input Unit, 24 VDC, 32 inputs 40
CJ1W-ID262 Input Unit, 24 VDC, 64 inputs
CJ1W-OD232 Transistor Output Unit with sourcing outputs, 32 outputs
CJ1W-OD262 Transistor Output Unit with sourcing outputs, 64 outputs
CJ1W-OD233 Transistor Output Unit with sinking outputs, 32 outputs
CJ1W-OD263 Transistor Output Unit with sinking outputs, 64 outputs
CJ1W-MD263 24-VDC Input/Transistor Output Units, 32 inputs, 32 outputs
CJ1W-MD563 TTL Input/TTL Output Units, 32 inputs, 32 outputs
CJ1W-MD232 24-VDC Input/Transistor Output Units, 16 inputs, 16 outputs 20
CJ1W-MD233 24-VDC Input/Transistor Output Units, 16 inputs, 16 outputs
Applicable Cable-side Connectors
Connection Pins OMRON set DDK parts
Pressure-welded 40 XG4M-4030-T FRC5-A040-3T0S
20 XG4M-2030-T FRC5-A020-3T0S

Omron CJ2 Specifications

General

Model	CJ2
Manufacturer	Omron
Type	Programmable Logic Controller (PLC)
CPU Units	Multiple models available (e.g., CJ2M, CJ2H)
Number of I/O Points	Up to 2, 560 points
Communication Ports	Ethernet/IP, EtherCAT, USB, Serial
Expansion	Yes, via I/O Units and Special I/O Units
I/O Control Method	Cyclic Scan, Interrupt
Programming Language	Ladder diagram, structured text, function block diagram, sequential function chart, instruction list
Built-in I/O	Available on some models (e.g., CJ2M)
Ethernet Port	Yes, 1 port (depending on CPU Unit)
Serial Ports	RS-232C, RS-422/485 (configurable)
USB Port	Yes (for programming and monitoring)
Operating Temperature	0°C to 55°C
Storage Temperature	-25 to 70°C
Humidity	10 to 95% RH (non-condensing)
Vibration Resistance	10 to 57 Hz, Amplitude: 0.075 mm, 57 to 150 Hz, Acceleration: 1 G, X, Y, and Z directions, 80 min each
Power Supply Voltage	24 VDC or 100 to 240 VAC (depending on CPU Unit)
