CJ2 CPU Unit Hardware User’s Manual
Program Error 0x80F0 A401.09: Pro-
gram Error Flag
A294 to A299:
Program Error
Information
The program is incorrect. See the fol-
lowing rows of this table for details.
The address at which the program
stopped will be output to A298 and
A299.
Check A295 to determine the type of error that
occurred and check A298/A299 to find the program
address where the error occurred. Correct the pro-
gram and then clear the error.
A295.11: No END error Be sure that there is an END(001) instruction at the
end of the task specified in A294 (program stop task
number).
A295.15: UM overflow error
The last address in UM (user pro-
gram memory) has been exceeded.
Transfer the program again.
A295.13: Differentiation overflow
error Too many differentiated instruc-
tions have been inserted or deleted
during online editing.
Return to PROGRAM mode and transfer the pro-
gram again.
A295.12: Task error
A task error has occurred. The follow-
ing conditions will generate a task
error.
1. There is no executable cyclic
task.
2. There is no task that corre-
sponds to the interrupt that was
input. (Only when the Stop CPU
on Instruction Error parameter in
the PLC Setup is set to Stop.)
Check the startup cyclic task attributes. Check the
execution status of each task as controlled by
TKON(820) and TKOF(821).Make sure that all of the
task numbers specified in TKON(820), TKOF(821),
and MSKS(690) instructions have corresponding
tasks. Use MSKS(690) to mask any I/O or sched-
uled interrupt tasks that are not being used and that
do not have programs set for them.
A295.10: Illegal access error
An illegal access error has occurred
and the PLC Setup has been set to
stop operation for an instruction error.
The following are illegal access
errors:
1. Reading/writing a parameter
area.
2. Writing memory that is not
installed.
3. Writing an EM bank that is EM
file memory.
4. Writing to a read-only area.
5. Indirect DM/EM address that is
not in BCD when BCD mode is
specified.
Find the program address where the error occurred
(A298/A299) and correct the instruction.
A295.09: Indirect DM/EM BCD error
An indirect DM/EM BCD error has
occurred and the PLC Setup has
been set to stop operation for an
instruction error.
Find the program address where the error occurred
(A298/A299) and correct the indirect addressing or
change to binary mode.
A295.08: Instruction error
An instruction processing error has
occurred and the PLC Setup has
been set to stop operation for an
instruction error.
Find the program address where the error occurred
(A298/A299) and correct the instruction.
A295.14: Illegal instruction error
The program contains an instruction
that cannot be executed.
Retransfer the program to the CPU Unit.
Error
Error
code
(inA400)
Error flag
(Auxiliary
Area)
Flag and
word data
Probable cause Possible remedy

Omron CJ2 Specifications

General

Model	CJ2
Manufacturer	Omron
Type	Programmable Logic Controller (PLC)
CPU Units	Multiple models available (e.g., CJ2M, CJ2H)
Number of I/O Points	Up to 2, 560 points
Communication Ports	Ethernet/IP, EtherCAT, USB, Serial
Expansion	Yes, via I/O Units and Special I/O Units
I/O Control Method	Cyclic Scan, Interrupt
Programming Language	Ladder diagram, structured text, function block diagram, sequential function chart, instruction list
Built-in I/O	Available on some models (e.g., CJ2M)
Ethernet Port	Yes, 1 port (depending on CPU Unit)
Serial Ports	RS-232C, RS-422/485 (configurable)
USB Port	Yes (for programming and monitoring)
Operating Temperature	0°C to 55°C
Storage Temperature	-25 to 70°C
Humidity	10 to 95% RH (non-condensing)
Vibration Resistance	10 to 57 Hz, Amplitude: 0.075 mm, 57 to 150 Hz, Acceleration: 1 G, X, Y, and Z directions, 80 min each
Power Supply Voltage	24 VDC or 100 to 240 VAC (depending on CPU Unit)
