2-11
2 Basic System Configuration and Devices
CJ2 CPU Unit Hardware User’s Manual
2-1 Basic System Configuration
2
2-1-4 Configuration Units
z CJ-series Basic I/O Units
Input Units
*1 The cable-side connector is not provided with Units equipped with cables. Purchase the cable separately
(Refer to 5-3-3 Wiring Basic I/O Units with Connectors.), or use an OMRON Connector- Terminal Block Con-
version Unit or I/O Terminal (Refer to 5-3-4 Connecting to Connector-Terminal Block Conversion Units or I/O
Relay Terminals.).
*2 Although 16 I/O bits are allocated, only 8 of these can be used for external I/O. This Unit is also treated as a
16-point I/O Unit in the I/O tables.
*3 An Interrupt Input Unit can be connected only in a CJ-series CPU Rack. When using the CJ2H-CPU@@-EIP,
connect the Interrupt Input Units in slots 0 to 3 in the CPU Rack. An I/O setting error will occur if the Unit is con-
nected in other positions in the CPU Rack or to any position in an Expansion Rack. Up to two Interrupt Input
Units can be connected.
Configuration Units
Name Specifications Model
Number of
bits allo-
cated
Current consumption
(A)
Weight
5 VDC 24 VDC
DC Input
Units
Terminal block
12 to 24 VDC, 8 inputs
CJ1W-ID201
16
*2
0.08 --- 110 g max.
Terminal block
24 VDC, 16 inputs
CJ1W-ID211 16 0.08 --- 110 g max.
Fujitsu-compatible con-
nector
24 VDC, 32 inputs
CJ1W-ID231
*1
32 0.09 --- 70 g max.
MIL connector
24 VDC, 32 inputs
CJ1W-ID232
*1
32 0.09 --- 70 g max.
Fujitsu-compatible con-
nector
24 VDC, 64 inputs
CJ1W-ID261
*1
64 0.09 --- 110 g max.
MIL connector
24 VDC, 64 inputs
CJ1W-ID262
*1
64 0.09 --- 110 g max.
AC Input
Units
200 to 240 VAC,
8 inputs
CJ1W-IA201
16
*2
0.08 --- 130 g max.
100 to 120 VAC,
16 inputs
CJ1W-IA111 16 0.09 --- 130 g max.
Interrupt Input
Units
24 VDC, 16 inputs
CJ1W-INT01
*3
16 0.08 --- 110 g max.
Quick-
response
Input Units
24 VDC, 16 inputs CJ1W-IDP01 16 0.08 --- 110 g max.
B7A Interface
Units
64 inputs CJ1W-B7A14 64 0.09 --- 80 g max.
