CJ2 CPU Unit Hardware User’s Manual
Output Units
*1 The cable-side connector is not provided with Units equipped with cables. Purchase the cable separately
(Refer to 5-3-3 Wiring Basic I/O Units with Connectors.), or use an OMRON Connector- Terminal Block Con-
version Unit or I/O Terminal (Refer to 5-3-4 Connecting to Connector-Terminal Block Conversion Units or I/O
Relay Terminals.).
*2 Although 16 I/O bits are allocated, only 8 of these can be used for external I/O. This Unit is also treated as a
16-point I/O Unit in the I/O tables.
Name Specifications Model
Number of
bits allo-
cated
Current consumption
(A)
Weight
5 VDC 24 VDC
Relay Output Units Terminal block, 250 VAC/24
VDC, 2 A; 8 points, indepen-
dent contacts
CJ1W-OC201
16
*2
0.09 0.048
(0.006
× Num-
ber of ON out-
puts)
140 g max.
Terminal block, 250 VAC/24
VDC, 2 A; 16 points
CJ1W-OC211 16 0.11 0.096
(0.006
× Num-
ber of ON out-
puts)
170 g max.
Triac Output Unit Terminal block, 250 VAC, 0.6
A; 8 points
CJ1W-OA201
16
*2
0.22 --- 150 g max.
Transis-
tor Out-
put Units
Sinking
outputs
Terminal block, 12 to 24 VDC,
2 A;
8 outputs
CJ1W-OD201
16
*2
0.09 --- 110 g max.
Terminal block, 12 to 24 VDC,
0.5 A;
8 outputs
CJ1W-OD203
16
*2
0.10 --- 110 g max.
Terminal block, 12 to 24 VDC,
0.5 A;
16 outputs
CJ1W-OD211 16 0.10 --- 110 g max.
Fujitsu-compatible connec-
tor, 12 to 24 VDC, 0.5 A;
32 outputs
CJ1W-OD231
*1
32 0.14 --- 70 g max.
MIL connector, 12 to 24 VDC,
0.3 A; 32 outputs
CJ1W-OD233
*1
32 0.14 --- 70 g max.
Fujitsu-compatible connec-
tor, 12 to 24 VDC, 0.3 A;
64 outputs
CJ1W-OD261
*1
64 0.17 --- 110 g max.
MIL connector, 12 to 24 VDC,
0.3 A;
64 outputs
CJ1W-OD263
*1
64 0.17 --- 110 g max.
Sourc-
ing out-
puts
Terminal block, 24 VDC, 2 A;
8 outputs, load short-circuit
protection and disconnected
line detection
CJ1W-OD202
16
*2
0.11 --- 120 g max.
Terminal block, 24 VDC, 0.5
A; 8 outputs, load short-cir-
cuit protection
CJ1W-OD204
16
*2
0.10 --- 120 g max.
Terminal block, 24 VDC, 0.5
A; 16 outputs, load short-cir-
cuit protection
CJ1W-OD212 16 0.10 --- 120 g max.
MIL connector, 24 VDC, 0.5
A; 32 outputs, load short-cir-
cuit protection
CJ1W-OD232
*1
32 0.15 --- 80 g max.
MIL connector, 12 to 24 VDC,
0.3 A;
64 outputs
CJ1W-OD262
*1
64 0.17 --- 110 g max.
B7A Interface Units 64 outputs CJ1W-B7A04 64 0.07 --- 80 g max.

Omron CJ2 Specifications

General

Model	CJ2
Manufacturer	Omron
Type	Programmable Logic Controller (PLC)
CPU Units	Multiple models available (e.g., CJ2M, CJ2H)
Number of I/O Points	Up to 2, 560 points
Communication Ports	Ethernet/IP, EtherCAT, USB, Serial
Expansion	Yes, via I/O Units and Special I/O Units
I/O Control Method	Cyclic Scan, Interrupt
Programming Language	Ladder diagram, structured text, function block diagram, sequential function chart, instruction list
Built-in I/O	Available on some models (e.g., CJ2M)
Ethernet Port	Yes, 1 port (depending on CPU Unit)
Serial Ports	RS-232C, RS-422/485 (configurable)
USB Port	Yes (for programming and monitoring)
Operating Temperature	0°C to 55°C
Storage Temperature	-25 to 70°C
Humidity	10 to 95% RH (non-condensing)
Vibration Resistance	10 to 57 Hz, Amplitude: 0.075 mm, 57 to 150 Hz, Acceleration: 1 G, X, Y, and Z directions, 80 min each
Power Supply Voltage	24 VDC or 100 to 240 VAC (depending on CPU Unit)
