Omron CPM2C User Manual

223
Introduction Section 7-1
Note 1. The CPM2C-CIF21 can be used only with the CPM2C.
2. Up to 32 OMRON components can be connected.
Supported Components The following table shows the OMRON components equipped with Compo-
Way/F or SYSWAY communications functions that can be connected to the
CPM2C-CIF21.
Note 1. Components that support only host link or CompoWay/F communications
must be connected with that communications protocol.
Bottom port Signal con-
version
Outputs the RS-232C interface directly from the CPU
Unit.
Function Host Link, no-protocol, 1:1 link, or 1:1 NT Link
Product
name
Series name Model
number
SYSWAY CompoWay/F
connection
Comments
Connection Segment
info. (See
note 5.)
Temperature
Controllers
Temperature Con-
trollers
E5GN OK 1 OK ---
E5CN OK 1 OK ---
E5EN OK 1 OK ---
E5AN OK 1 OK ---
Digital Controllers,
Standard Models
E5CK OK 1 No ---
E5EK OK 1 No ---
E5AK OK 1 No ---
Digital Controllers
(Valve Control)
E5EK OK 1 No Valve system commu-
nications are not sup-
ported.
E5AK OK 1 No
Digital Controllers
(Programmable)
E5CK-T No --- No ---
E5EK-T No --- No ---
E5AK-T No --- No ---
Digital Controllers
(Programmable,
Valve Control)
E5EK-T No --- No ---
E5AK-T No --- No ---
Temperature Con-
trollers
E5EJ OK 1 No ---
E5AJ OK 1 No ---
Fuzzy Tempera-
ture Controller
E5AF OK 1 No ---
Modular Tempera-
ture Controller
E5ZN No --- OK ---
Digital Controller
Board
E5ZM No --- OK ---
Timers Electronic Timer/
Counter
H8GN No --- OK ---
Digital Panel
Meters
Digital Panel Meter K3GN No --- OK ---
Process Meter K3NX Limited functions 2 Limited functions Some commands
cannot be used.
Only the CompoWay/
F variable area can be
read. (See note 3.)
Weighing Meter K3NV Limited functions 2 Limited functions
Frequency/Rate
Meter
K3NR Limited functions 2 Limited functions
Period Meter K3NP Limited functions 2 Limited functions
Up/Down Counting
Meter
K3NC Limited functions 2 Limited functions
Temperature Meter K3NH Limited functions 2 Limited functions
Intelligent Signal
Processor
K3TS Limited functions 2 No SYSWAY connection
only (See note 2.)
