Omron CPM2C User Manual

46
Specifications Section 2-1
2-1-4 AC Power Supply Unit Specifications
Item Specification
Rating 24 VDC, 600 mA
Efficiency 75% min. (at rated output)
Input conditions Rated voltage 100 to 240 VAC
Frequency 47 to 63 Hz
Allowable voltage range 85 to 264 VAC
Current 100 V 0.4 A
200 V 0.2 A
Leakage current 100 V 0.5 mA max. (at rated output)
200 V 1 mA max. (at rated output)
Inrush current 100 V 15 A (at 25°C cold start)
200 V 30 A (at 25°C cold start)
Output character-
istics
Output voltage accuracy 10%/–15% (including input, load, and temperature fluctuations)
Minimum output current 30 mA
Ripple noise voltage 2% (p-p) max.
Input fluctuation 0.75% max.
Load fluctuation 4% max.
Temperature fluctuation 0.05%/°C max.
Startup time 300 ms max. (at input voltage of 100 VAC or 200 VAC and the rated out-
put)
Output hold time 10 ms (at input voltage of 100 VAC or 200 VAC and the rated output)
Overcurrent protection Self-resetting, operates at 105% to 350% of the rated current, suspended
and independent operation
Overvoltage protection None
Ambient operating temperature 0 to 55°C
Ambient storage temperature –20 to 75°C
Ambient operating humidity 10% to 90% (no condensation)
Dielectric strength 2,000 V for 1 min between all inputs and GR
Leakage current: 10 mA
3,000 V for 1 min between all inputs and all outputs
Leakage current: 10 mA
1,000 V for 1 min between all outputs and GR
Leakage current: 10 mA
Insulation resistance 100 MΩ min. at 500 VDC between all outputs and any input, and between
all outputs and GR
Vibration resistance
10 to 57 Hz, amplitude, 57 to 150 Hz, acceleration: 9.8 m/s
2
in X, Y, and Z
directions for 80 minutes according
(Time coefficient: 8 minutes × coefficient factor 10 = total time 80 min.)
Shock resistance
147 m/s
2
3 times each in X, Y, and Z directions
Noise terminal voltage FCC class A
